They are widely used because they are ready-to-use, practical and robust. These products, also known as Orthofix Type fixators, are preferred by orthopedic surgeons all over the world.
Monolateral external fixators are produced in 3 different sizes suitable for tibia, femur and humerus.
Each of the products is presented as ready to be sterilized and ready to use, with 6 schanz screws and allen key.
The body of all schanz screws, which is fixed by the fixator clamp, is designed as 6 mm.
The threaded part of the schanz screws are:
For the femur, it is 6 mm in diameter and 200 mm in length.
For the tibia, it is 5 mm in diameter and 180 mm in length.
For the humerus, it is 4 mm in diameter and 150 mm in length.
| Parts: | Qty |
|---|---|
| Monolateral Fixator (Humerus) | 1 |
| Schanz Screw (4.0 mm x 150 mm) | 6 |
| Allen Key | 1 |
| Monolateral Fixator (Femur) | 1 |
| Schanz Screw (6.0 mm x 200 mm) | 6 |
| Allen Key | 1 |
| Monolateral Fixator (Tibia) | 1 |
| Schanz Screw (5.0 mm x 180 mm) | 6 |
| Allen Key | 1 |
